DN50 (2" NB) ASA300 2" NPT GALVANISED THREADED FLANGE CS A105N
Outside diameter (O): 165.1mm
Hub diameter at base (C): 22.3mm
Length through hub (X): 84.0mm
Pitch circle diameter (K): 127.0mm
Raised face diameter (Y): 33.2mm
Raised face height (RF): 1.5mm
Hub diameter at top (R): 91.9mm
Bore diameter (Q): 63.5mm
Hub thickness (T): 28.4mm
Number of bolt holes: 8
Material: A105N Galvanised
Rating: ASA 300
Threaded: NPT
Type: Screwed flange (ASME B16.5)
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification
Alternative terminology:
Threaded Flange, Screwed Flange, ASA300, NPT, Carbon Steel, Raised Faced
Internal Reference:
CS-NB-FLA-50-FF-SCR-300-A105N-GAL
