  3. DN80 (3" NB) SCHEDULE 40 ASME B16.5 / ASA150 WELD NECK FLANGE ASTM A182 F9
List 200
DN80 (3" NB) SCHEDULE 40 ASME B16.5 / ASA150 WELD NECK FLANGE ASTM A182 F9

DN80 (3" NB) SCHEDULE 40 ASME B16.5 / ASA150 WELD NECK FLANGE ASTM A182 F9

https://www.integraflow.co.uk/web/image/product.template/22201/image_1920?unique=4630f72
(0 review)

Outside diameter (O): 190.5mm
Flange thickness (C): 23.8mm
Hub length (X): 101.6mm
Neck height (A): 88.9mm
Pitch circle diameter (K): 152.4mm
Hub base diameter (Y): 69.8mm
Raised face height (RF): 15.5mm
Raised face diameter (R): 127.0mm
Number of bolt holes: 4
Material: F9 ASTM A182
Rating: ASA 150
Type: Weld Neck Flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
WN Flange, Welding Neck, ASA150, F9, RF

Part of our Flanges and Flanged Connections Range

£ 237.00 237.0 GBP £ 237.00 Tax Excluded

Contact us for pricing

    This combination does not exist.

    ​

    Contact Us



    Terms and Conditions
    Shipping: Generally 2-3 Business Days
    Please contact us for accurate lead times.

    Share

    Trustpilot

    Internal Reference: F9-NB-FLA-80-RF-WN-STD-S40-A150-A105N
