DN25 (1" NB) JIS 5K FF SLIP ON FLANGE FLANGE A105 N (EUROPEAN ORIGIN)
Suits an outside diameter (OD) of: 33.4mm
Material: Carbon Steel
Grade: A105 N
Standards: JIS B2220 5K
Flange Face: Flat
Bolt Holes: 4 off to suit M10 Bolts
PCD: 90mm
Flange Diameter: 120mm
Flange Thickness: 10mm
Certification Available: 3.1 BS EN 10204 Material Certification
Origin: European (EU)
Alternative terminology:
Slip on, Raised Face, FFSO, Weld on, Mild Steel, Carbon Steel
| Size (Inch) | 1" |
| Outside Diameter (mm) | 33.40mm |
Internal Reference:
CS-NB-FLA-25-FF-5K-A105-EU
Specifications
| Size (Inch) | 1" |
| Outside Diameter (mm) | 33.40mm |
