DN15 (1/2" NB) BSP GALVANISED MALLEABLE IRON1/4" BSPP BOSSED MUNSEN PIPE RING
Suits pipe size: 1/2" NB
Suits an outside diameter (OD) of: 21.3mm
Material: Malleable Iron
Finish: HOT DIP GALVANISED (HDG)
Standards:
Nominal Bore, Threaded, Screwed, Low Pressure, 150 psi, Malleable Iron, EN 10242 & EN 10226-1
Alternative terminology:
Malleable, Iron, Threaded, Pipe Ring, Munsen Ring, Pipe Clip, Munson, Tube Clip, Screwed, Fittings.
| Size (Inch) | 1/2", 1/4" |
| Outside Diameter (mm) | 21.30mm |
Internal Reference:
MI-NB-8B-RING-15-GAL
Specifications
| Size (Inch) | 1/2", 1/4" |
| Outside Diameter (mm) | 21.30mm |
