Side One suits an outside diameter (OD) of: 168.3mm
Side One wall thickness (WT): 7.11mm

Side Two suits an outside diameter (OD) of: 114.3mm
Side Two wall thickness (WT): 6.02mm

Material: Carbon Steel
Grade: A234 WPB
Standards: ASME B16.9
Reduction style: Concentric
Construction: Seamless
Overall Length: 140mm
Ends: Buttweld
Certification Available: 3.1 BS EN 10204 Material Certification


Applications:
Water, Oil & Gas / Petrochem, Steam, Fuels, Condensate, HVAC, Marine, Water & Waste Water, Mining, Construction, Power Generation (Energy), Waste to Energy (ERF)

Alternative terminology:
Butt Weld, Con Reducer, Conred, Concentric

Side One suits an outside diameter (OD) of: 168.3mm
Side One wall thickness (WT): 10.97mm

Side Two suits an outside diameter (OD) of: 114.3mm
Side Two wall thickness (WT): 8.56mm

Material: Carbon Steel
Grade: A234 WPB
Standards: ASME B16.9
Reduction style: Concentric
Construction: Seamless
Overall Length: 140mm
Ends: Buttweld
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Butt Weld, Con Reducer, Conred, Concentric

Side One suits an outside diameter (OD) of: 168.3mm
Side One wall thickness (WT): 10.97mm

Side Two suits an outside diameter (OD) of: 114.3mm
Side Two wall thickness (WT): 8.56mm

Material: Carbon Steel
Grade: A234 WPB
Standards: ASME B16.9
Reduction style: Concentric
Construction: Seamless
Overall Length: 140mm
Ends: Buttweld
Certification Available: 3.1 BS EN 10204 Material Certification
Origin: European

Alternative terminology:
Butt Weld, Con Reducer, Conred, Concentric

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 114mm
Wall Thickness: 7.11 X 6.02mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 141mm
Wall Thickness: 7.11 X 6.55mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 73mm
Wall Thickness: 7.11 X 5.16mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 89mm
Wall Thickness: 7.11 X 5.49mm
Length: 140mm

Outside Diameter (OD): 168 X 102mm
Wall Thickness: 7.11 X 5.74mm
Length: 140mm

Outside Diameter (OD): 168 X 102mm
Wall Thickness: 7.11 X 5.74mm
Length: mm

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 3.40 x 3.05mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 10S
Weight: 5.10kg

Material: Stainless Steel
Material Grade: 304

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 3.40 x 3.05mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 10S
Weight: 5.10kg

Material: Stainless Steel
Material Grade: 316

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 3.40 x 3.05mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 10S
Weight: 5.10kg

Material: Stainless Steel
Material Grade: 304

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 3.40 x 3.05mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 10S
Weight: 5.10kg

Material: Stainless Steel
Material Grade: 316

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 7.11 x 6.02mm
Centre to End (Run): 143mm
Centre to End (Branch): 124mm
Schedule: STD
Weight: 14.0kg

Material: Mild Steel
Material Grade: ASTM A234 WPB
Finish: Black Varnished (Self Colour or Shotblasting on request)
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 7.11 x 6.02mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 40s
Weight: 14.0kg

Material: Stainless Steel
Material Grade: 304

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 7.11 x 6.02mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 40s
Weight: 14.0kg

Material: Stainless Steel
Material Grade: 316

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 7.11 x 6.02mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 40s
Weight: 14.0kg

Material: Stainless Steel
Material Grade: 304

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 7.11 x 6.02mm
Centre to End (Run): 143mm
Centre to End (Branch): 130mm
Schedule: 40s
Weight: 14.0kg

Material: Stainless Steel
Material Grade: 316

Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Outside Diameter (OD): 168 x 114mm
Wall Thickness (Run x Branch): 10.97 x 8.56mm
Centre to End (Run): 143mm
Centre to End (Branch): 124mm
Schedule: XS
Weight: 19.3kg

Material: Mild Steel
Material Grade: ASTM A234 WPB
Finish: Black Varnished (Self Colour or Shotblasting on request)
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative Terminology: Buttweld Tee, Reducing Tee, LR, Welding Tee, Weldable

Suits an outside diameter (OD) of: 154mm
Band width: 40mm
Band thickness: 5mm
Bolt Size: M12
Material: Stainless Steel
Grade: 304

Connection: 3/4" SW (Socket Weld)
Suits an outside diameter (OD) of: 26.9mm
Material: Forged Stainless Steel
Grade: 316
Construction: Forged
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Union, FXF, Stainless Steel

Outside diameter (O): 381.0mm
Flange thickness (C): 41.1mm
Hub height (X): 260.3mm
Length through hub (A): 219.2mm
Bolt circle diameter (K): 304.8mm
Overall height (Y): 111.2mm
Raised face thickness (RF): 1.5mm
Bore (B): 269.7mm
Number of bolt holes: 12
Bolt hole diameter: 25.4mm
Approx. weight: 31.0kg

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 381.0mm
Flange thickness (C): 41.1mm
Hub height (X): 260.3mm
Length through hub (A): 219.2mm
Bolt circle diameter (K): 304.8mm
Overall height (Y): 111.2mm
Raised face thickness (RF): 1.5mm
Bore (B): 269.7mm
Number of bolt holes: 12
Bolt hole diameter: 25.4mm
Approx. weight: 31.0kg

Part of our Flanges and Flanged Connections Range

8" Ductile Iron Ball Valve – Direct Mount – Flanged ASA150

Face to face: 400mm

Direct mount with lever


Flanged ASA150 connections with ISO 5211 direct mount interface.
Ductile iron body with brass ball and stem.
Fitted with RPTFE seats and NBR O-rings.
Steel lever operated.

Face to face: DIN 3202 F5 (8”).
Pressure rating: ASA150.
Temperature range: -10°C to 100°C.

Part of our Isolation and Valves Range

Suits an outside diameter (OD) of: 219.1mm
Material: CS
Grade: A105 N
Standards: ANSI / ASA150
Flange Face: Raised
Bolt Holes: 8 off 22mm Ø
PCD: 298.4mm
Flange Diameter: 342.9mm
Flange Thickness: 28.4mm
Certification Available: 3.1 Material Certification

Alternative terminology:
Blind, Blank, Blanking Flange, Mild steel, Carbon Steel, Termination, RFB

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 343.0mm
Flange thickness (C): 28.6mm
Pitch circle diameter (K): 298.5mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 8
Material: A105N
Rating: ASA 150
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA150, Carbon Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 343.0mm
Flange thickness (C): 28.6mm
Pitch circle diameter (K): 298.5mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 8
Material: Stainless Steel 304
Rating: ASA 150
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA150, Stainless Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 343.0mm
Flange thickness (C): 28.6mm
Pitch circle diameter (K): 298.5mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 8
Material: Stainless Steel 316
Rating: ASA 150
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA150, Stainless Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 342.9mm (O)
Flange thickness: 28.4mm (C)
Flange hub height: 44.4mm (Y)
Pitch Circle Diameter (PCD): 298.4mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 8 off 22.3mm diameter
Bore Diameter: 221.4mm (B)
Material: Carbon Steel
Grade: A105N
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Carbon Steel, Raised Faced, ASA 150LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 342.9mm (O)
Flange thickness: 28.4mm (C)
Flange hub height: 44.4mm (Y)
Pitch Circle Diameter (PCD): 298.4mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 8 off 22.3mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 304
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 150LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 342.9mm (O)
Flange thickness: 28.4mm (C)
Flange hub height: 44.4mm (Y)
Pitch Circle Diameter (PCD): 298.4mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 8 off 22.3mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 316
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 150LB, SOB

Part of our Flanges and Flanged Connections Range

Slip on Bossed Flange
Suits an outside diamter of: 219.1mm
Material: CS
Grade: A105N
Standards: ASME B16.9 / ASA150
Flange Face: Raised
Bolt Holes: 8 off 22.3mm Ø
PCD: 298.4mm
Flange Diameter: 342.9mm
Flange Thickness: 28.4mm
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on, Bossed Flange, Weld on, Mild Steel, Carbon Steel

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 482.6mm
Flange thickness (C): 98.4mm
Pitch circle diameter (K): 393.7mm
Raised face height (RF): 6.3mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 12
Material: A105N
Rating: ASA 1500
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA1500, Carbon Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 482.6mm (O)
Flange thickness: 91.9mm (C)
Flange hub height: 69.9mm (Y)
Pitch Circle Diameter (PCD): 393.7mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 44.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Carbon Steel
Grade: A105N
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Carbon Steel, Raised Faced, ASA 1500LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 482.6mm (O)
Flange thickness: 91.9mm (C)
Flange hub height: 69.9mm (Y)
Pitch Circle Diameter (PCD): 393.7mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 44.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 304
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 1500LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 482.6mm (O)
Flange thickness: 91.9mm (C)
Flange hub height: 69.9mm (Y)
Pitch Circle Diameter (PCD): 393.7mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 44.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 316
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 1500LB, SOB

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 381.0mm
Flange thickness (C): 41.1mm
Pitch circle diameter (K): 330.2mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 12
Material: A105N
Rating: ASA 300
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 2.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA300, Carbon Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 381.0mm
Flange thickness (C): 41.1mm
Pitch circle diameter (K): 330.2mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 12
Material: Stainless Steel 304
Rating: ASA 300
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 2.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA300, Stainless Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 381.0mm
Flange thickness (C): 41.1mm
Pitch circle diameter (K): 330.2mm
Raised face height (RF): 1.5mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 12
Material: Stainless Steel 316
Rating: ASA 300
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 2.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA300, Stainless Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 381.0mm (O)
Flange thickness: 41.1mm (C)
Flange hub height: 61.9mm (Y)
Pitch Circle Diameter (PCD): 330.2mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 12 off 25.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Carbon Steel
Grade: A105N
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Carbon Steel, Raised Faced, ASA 300LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 381.0mm (O)
Flange thickness: 41.1mm (C)
Flange hub height: 61.9mm (Y)
Pitch Circle Diameter (PCD): 330.2mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 12 off 25.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 304
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 300LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 381.0mm (O)
Flange thickness: 41.1mm (C)
Flange hub height: 61.9mm (Y)
Pitch Circle Diameter (PCD): 330.2mm (K)
Raised Face Height: 1.5mm (RF)
Bolt Holes: 12 off 25.4mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 316
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 300LB, SOB

Part of our Flanges and Flanged Connections Range

Outside diameter (O): 412.8mm
Flange thickness (C): 63.5mm
Pitch circle diameter (K): 349.2mm
Raised face height (RF): 6.3mm
Raised face diameter (R): 269.7mm
Number of bolt holes: 12
Material: A105N
Rating: ASA 600
Type: Blind flange (ASME B16.5)

Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 2.1 BS EN 10204 Material Certification

Alternative terminology:
Blind Flange, Blank, ASA600, Carbon Steel, Raised Faced

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 419.1mm (O)
Flange thickness: 55.6mm (C)
Flange hub height: 76.2mm (Y)
Pitch Circle Diameter (PCD): 349.6mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 31.7mm diameter
Bore Diameter: 221.4mm (B)
Material: Carbon Steel
Grade: A105N
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Carbon Steel, Raised Faced, ASA 600LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 419.1mm (O)
Flange thickness: 55.6mm (C)
Flange hub height: 76.2mm (Y)
Pitch Circle Diameter (PCD): 349.6mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 31.7mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 304
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 600LB, SOB

Part of our Flanges and Flanged Connections Range

Flange outside diameter: 419.1mm (O)
Flange thickness: 55.6mm (C)
Flange hub height: 76.2mm (Y)
Pitch Circle Diameter (PCD): 349.6mm (K)
Raised Face Height: 6.3mm (RF)
Bolt Holes: 12 off 31.7mm diameter
Bore Diameter: 221.4mm (B)
Material: Stainless Steel
Grade: 316
Standards: ASME B16.5
Flange Face: Raised Face
Certification Available: 3.1 BS EN 10204 Material Certification

Alternative terminology:
Slip on Flange, Weld on, Stainless Steel, Raised Faced, ASA 600LB, SOB

Part of our Flanges and Flanged Connections Range

Suits an outside diameter (OD) of: 219.1mm
Material: Stainless Steel 304 (A2)
Thread: M20
Comes with 2x Nuts

Connection: 8" NB Flange
Suits an outside diameter (OD) of: 219.1mm
Connection: Slip on / Flanged
Material: Mild Steel
Grade: S235 JR
Finish: Hot Dip Galvanised
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)

Connection: 8" NB Flange
Suits an outside diameter (OD) of: 219.1mm
Connection: Slip on / Flanged
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)

Connection: 8" NB Solvent
Suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Connection both ends: 8" NB Solvent
Side One suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Connection both ends: 8" NB Solvent
Side One suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Connection both ends: 8" NB Solvent
Side One suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Connection both ends: 8" NB Solvent
Side One suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Connection: 8" NB Solvent
Suits an outside diameter (OD) of: 219.1mm
Connection: Plain Glued / Solvent Cement
Material: PVC-U
Standards: EN 1452-3, BS 4346 Part 1
Pressure: 9 Bar (At 0°C) / 1.3 Bar (At 60°C)
Approvals: WRAS (Meets the requirements
Of the Water Regulations Advisory Scheme
for potable water.)

Suits an outside diameter (OD) of: 219.1mm
Boss Connection: M16
Band width: 50mm
Band thickness: 6mm
Bolt Size: M16
Material: MS
Finish: Zinc Plated

Suits Flange Size: DN200 (See suitable flange tables below)
Valve Type: Butterfly Valve
Mounting Standard: ISO 5211 Direct Mount
Body Material: Epoxy Coated Ductile Iron
Disc Material: 316 Stainless Steel
Liner Material: EPDM
Operation: Locking Lever
Pressure Rating: PN16
Temperature Range: -10°C to +120°C (130°C peak)
Certification: Complies with 97/23/CE (PED) Directive CE 1115
Approval: WRAS Approved
Flange Suitability: PN6/10/16, ANSI 150, Table D & Table E

Alternative terminology: Wafer Butterfly Valve, Lever Operated Butterfly Valve, Gear Operated Butterfly, Isolation Valve, Shut-Off Valve

Part of our Isolation and Valves Range

Part of our Flanges and Flanged Connections Range

Part of our Flanges and Flanged Connections Range

Suits a pressed collar: 219.1mm (ISO)
Material: Aluminium
Grade: UNI 2223
Standards: EN1092-1
Flange Face: Flat
Chamfered internal (To suit collar / stub flange)
Bolt Holes: 8 off to suit M20 Bolts
PCD: 295mm
Flange Diameter: 340mm

Flange OD (D): 340mm
Drilling (No. x Bolt Holes x L): 8 x M20 x 22mm
Pitch circle diameter (K): 295mm
Flange thickness (C4): 24~mm
Material: S235 JR
Rating: PN10
Type: Blind flange (EN1092-1 Type 05)

Standards: EN1092-1
Flange Face: Flat Face
Certification Available: 2.1 BS EN 10204 Material Certification

Alternative terminology:
Blank Flange, Blind, Mild Steel, Carbon Steel, Flat Faced, FF Blind

Part of our Flanges and Flanged Connections Range

Flanged to suit: 8" PN10
Body Material: Cast Iron
Seat Material: Cast Brass
Stem Material: Stainless Steel
Flange Drilling: PN16 (8” also available PN10)
Stem Type: Inside Screw, Non-Rising Stem
Face-to-Face: 230mm (DIN 3202 F4)
Temperature Range: -10°C to +120°C
Pressure Rating: PN16

Alternative terminology: Flanged Gate Valve, Isolation Valve, Shut-Off Valve, Wedge Gate Valve, Manual Gate Valve

Part of our Isolation and Valves Range

Suits an outside diameter (OD) of: 219.1mm
Material: Rubber
Grade: EPDM
Standards: EN1092-1
Gasket Thickness: 3mm
