Suits a 1" NB (33.7mm) Handrail
Finish: Self Colour
Material: MS

Suits a 1.1/4" NB (42.4mm) Handrail
Finish: Self Colour
Material: MS

Handrail Clamp Galvanised Short Tee to suit 42.4mm OD Handrail
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key)
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect Two handrails together at a 90 degree angle allowing the tube to pass through the top run of the tee.

Handrail Clamp 90° Galvanised Elbow to suit 26.9mm OD Handrail
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key)
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect Two handrails together at a 90 degree angle.

Handrail Clamp 90° Galvanised Elbow to suit 33.4mm OD Handrail
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key)
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect Two handrails together at a 90 degree angle.

Handrail Clamp 90° Galvanised Elbow to suit 42.4mm OD Handrail
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key)
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect Two handrails together at a 90 degree angle.

Handrail Clamp Single Mesh Clip to suit 33.4mm OD Handrail
Finish: Galvanised
Connection: Comes with fasteners to secure in place
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect a mesh panel to the handrail on one side.

Handrail Clamp Single Mesh Clip to suit 42.4mm OD Handrail
Finish: Galvanised
Connection: Comes with fasteners to secure in place
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect a mesh panel to the handrail on one side.

Handrail Clamp Double Mesh Clip to suit 33.4mm OD Handrail
Finish: Galvanised
Connection: Comes with fasteners to secure in place
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect a mesh panel to the handrail on both sides.

Handrail Clamp Double Mesh Clip to suit 42.4mm OD Handrail
Finish: Galvanised
Connection: Comes with fasteners to secure in place
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect a mesh panel to the handrail on both sides.

Handrail Clamp D Return end of rail bend to suit 42.4mm OD Handrail with 550mm Centres
Finish: Galvanised
Connection: Plain end to cut to length
Material: Mild Steel

Application:
For use on galvanised handrail systems to connect a mesh panel to the handrail on one side.

Handrail Clamp K40 Kickplate toe clamp to suit 42.4mm OD Handrail
Finish: Galvanised
Connection: Comes with grub screw to secure in place
Material: Malleable Iron

Application:
For use on galvanised handrail systems to connect kick plate board to the handrail standards.

Handrail Standard / Stanchion / Stick with Flat Base
Balls to suit a 33.7mm OD Handrail
Ball Size: 60mm Diameter
Ball centres: 550 x 550mm
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key Required)
Material: MS

Handrail Standard / Stanchion / Stick with Flat Base
Balls to suit a 42.4mm OD Handrail
Ball Size: 60mm Diameter
Ball centres: 550 x 550mm
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key Required)
Material: MS

Handrail Standard / Stanchion / Stick with Side Base
Balls to suit a 33.7mm OD Handrail
Ball centres 550 x 550mm
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key Required)
Material: MS

Handrail Standard / Stanchion / Stick with Side Base
Balls to suit a 42.4mm OD Handrail
Ball centres 550 x 550mm
Finish: Galvanised
Connection: Comes with Grub Screws (Allen Key Required)
Material: MS
